[3.7v for 18650] BMS 4S 100A 14.8V 16.8V Li-ion Lithium Battery BMS
4S 14.8V to 16.8V 100A with Balance Charging Li-ion 18650 battery BMS Protection
This battery management system (BMS) is a four-string 14.4V Li-ion battery protection board with a balance charging capability. Overcharge protection, over-discharge protection, over-current protection, short circuit protection, and temperature protection are all included in this BMS.
Overcharge voltage range: 4.25VĀ±0.05V, upper working current: 100A, upper limit instantaneous current: 120A, overpressure voltage range: 2.5VĀ±0.05V.
SPECIFICATIONS
| Model | HX-4S-F100A orĀ HX-4S-B100A |
| Max.Ā Working Current | 100A |
| Max.Ā Instantaneous Current | 120A |
| Over Voltage Range | 4.25VĀ±0.05V |
| Overpressure Voltage Range | 2.5VĀ±0.05V |
| Charging Voltage | 14.4V |
| Charging Current | 10A |
| Short-Circuit Protection | Yes, 250Āµs delay recovery |
| Size | 70x60x8mm |
Ā
Original: $7.02
-70%$7.02
$2.11Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
4S 14.8V to 16.8V 100A with Balance Charging Li-ion 18650 battery BMS Protection
This battery management system (BMS) is a four-string 14.4V Li-ion battery protection board with a balance charging capability. Overcharge protection, over-discharge protection, over-current protection, short circuit protection, and temperature protection are all included in this BMS.
Overcharge voltage range: 4.25VĀ±0.05V, upper working current: 100A, upper limit instantaneous current: 120A, overpressure voltage range: 2.5VĀ±0.05V.
SPECIFICATIONS
| Model | HX-4S-F100A orĀ HX-4S-B100A |
| Max.Ā Working Current | 100A |
| Max.Ā Instantaneous Current | 120A |
| Over Voltage Range | 4.25VĀ±0.05V |
| Overpressure Voltage Range | 2.5VĀ±0.05V |
| Charging Voltage | 14.4V |
| Charging Current | 10A |
| Short-Circuit Protection | Yes, 250Āµs delay recovery |
| Size | 70x60x8mm |
